4. Device installation | 4.3 - Hardware construction | 33
4.3 Hardware construction
4.3.1 Network port
The device has an internal Ethernet port.
NOTICE
Damaged data will bring a stop to IT operations.
Protect the IT network to prevent unauthorized access.
The current IT security guidelines must be followed so as to minimize the
risks.
4.3.1.1 Ethernet port
The Ethernet port contains a powerful TCP/IP interface connection with
transfer rates of 10 or 100Mbit/s.
Technical data
Description Data
Connection
RJ-45 plug connector (female) on the device front
yellow (yel): lights up when there is an existing con
nection (link)
green (grn): flashing on data traffic (activity)
