Minebea Intec MiNexx-link-E PR 5215/01 User Manual

15. Specification | 15.4 - Weighing electronics data | 141
Fast transients (burst) EN61000-4-4 2kV
Peak voltages (surge) 1.2/50µs EN61000-4-5 1/2kV
Mains inputs
Conducted disturbances by
high frequency coupling (0.15…
80MHz)
EN61000-4-6 3V
15.3.3 RF interference suppression
Electromagnetic
emission
pursuant to EN61326, Limit classA, for
industrial areas
15.4 Weighing electronics data
15.4.1 Load cells
Load cell type Strain gauge
load cells
6 or 4-wire connection possible.
Supply voltage U
DC
=5V
– for I
max
= 66.6mA
– for max. 8load cells, each
with 650Ω
– 4load cells, each with 350Ω
Max. load ≥75Ω
