6. Operating | 6.3 - WEB menu | 80
– LC output impedance
Only by selection "All load cells same"
Input: from the calibration certificate of the load cell under "Output
impedance"
– LC 1…8 output at max. capacity
Only by selection "Each load cell specific"
Eingabe: from the calibration certificate of the load cell under "Output
at max. capacity"
– LC 1…8 output impedance
Only by selection "Each load cell specific"
Input: from the calibration certificate of the load cell under "Output
impedance"
6.3.2 Application settings
Limits ·
– Limit 1…3 on
Input: Weight value
– Limit 1…3 off
Input: Weight value
6.3.3 Interfaces
Serial Interface ·
– Protocol
Selection: Kein, Fernanzeige, SMA, Modbus-RTU
– Baud rate
Selection: 300, 600, 1200, 4800, 9600, 19200 baud
– Data bits
View: protocol-dependent
– Parity
View: protocol-dependent
– Stop bits
View: protocol-dependent
Digital Inputs & Outputs ·
– Input 1…3
Selection: None, Set zero, Set tare, Reset tare
– Output 1…3
Selection: None, ADC error, Limit 1, Limit 2, Limit 3, Tare active
