4. Device installation | 4.3 - Hardware construction | 40

Transmitter terminals

Terminal

contact

Connection Description Color

M+ + Meas. + Signal/LC output green

M- – Meas. – Signal/LC output gray

S+ + Sense + Sense white

S- – Sense – Sense black

PE Screen

+ + Supply + Supply/excitation red

– – Supply – Supply/excitation blue

PE Screen

Note:

The colors listed here apply for the MinebeaIntec products.

Color code

bk = black

bu = blue

gn = green

gy = gray

rd = red

wh = white

For additional information on the connection, refer to the corresponding

technical documentation.
