4. Device installation | 4.3 - Hardware construction | 50
Technical data (continued)
Description Data
Cable impedance 150Ω
Cable length The max. distance of 200m can be extended at
1.5Mbit/s by means of an additional repeater.
Certificates PROFIBUS Nutzerorganisation e.V. grants to HMS In
dustrial Networks AB
Certificate No: Z01951
Model Name: Anybus CompactCom 40 PROFIBUS
DP-V1
Revision: 1.8; SW/FW: 1.08; HW: 1.0
GSD: HMSA1815.GSD, File Version: 16-8-2019
Test Report Number: PCN214-DPS-01
Note: The GSD file is available to download online:
http://www.minebea-intec.com
ProfiBus connection
The device is the only/last slave in the bus.
* screen on connector housing
The device is not the only/last slave in the bus.
* screen on connector housing
