4. Device installation | 4.3 - Hardware construction | 53
Technical data (continued)
Description Data
Cable length Depends on cable type and transmission rate: 100 to
500m
Certificates Test Information
– Vendor Name: HMS Industrial Networks AB
– Composite Test Revision: CT25
– ODVA File Number: 11307.01
Product Information
– Network Category: Node
– Identity Object Instance
– Vendor ID (Attribute 1): 90
– Device Type (Attribute 2): 0x2B
– Device Profile: Name Generic Device (keyable)
– Product Code (Attribute 3): 63
– Product Name (Attribute 7): CompactCom 40 De
viceNet™
– Product Revision (Attribute 4): 1.006
– SOC File Name: 7129_DeviceNet.stc
Note:
The EDS file is available to download online:
http://www.minebea-intec.com
Allocation of the 5-pin plug connector
Pin assignment Signal Color Description
Cable sheath Special DeviceNet cable (certified)
1 V– black negative power supply
2 CAN_L blue CAN_L bus signal
3 S Cable screen
4 CAN_H white CAN_H bus signal
5 V+ red positive power supply
