2. Product presentation
MiR250 User Guide (en) 11/2020 - v.1.3 ©Copyright 2020: Mobile Industrial Robots A/S. 14
Pos. Description Pos. Description
5 Nanoscan3 safety laser
scanner: two pcs, in opposite
corners—see Obstacle
detection on page74
6 Status light: on all four sides
of the robot—see Light
indicators and speakers on
page101
7 Side cover: opens to side
compartment—see Internal
parts on page21
8 Control panel—see Control
panel on page16
9 Manual brake release
switch—see Control panel on
page16
10 Rear cover: opens to rear
compartment—see Internal
parts on page21
11 Signal light: eight pcs, two on
each corner—see Light
indicators and speakers on
page101
12 Proximity sensor: eight pcs,
two in each corner behind
corner covers—see Obstacle
detection on page74
13 Top plate 14 Left top compartment—see
Internal parts on page21
15 Right top compartment—see
Internal parts on page21
Identification label
MiR250 is delivered with an identification label mounted to the product. The identification
label identifies the product, the product serial number, and the hardware version of the
product.
The identification label of MiR250 is located behind the rear cover next to the battery.
