Mitel 6869 SIP System Manual

Installation
NT1 Cable cores Straight
patch cable
Communication server
1 TxA RxA 1
2 TxB RxB 2
3 – – 3
4 RxA TxA 4
5 RxB TxB 5
6 – – 6
7 – – 7
8 – – 8
4.7.2.2.3 Primary rate access in the private leased-line
network
Figure 31: Primary rate access, networked with copper line
Release 7.1
117 System Manual for Mitel SMB Controller
