Operation and Maintenance
• Every event:
This type of incoming event messages are all sent to the linked destination.
• Custom:
With this setting, you can determine how often the event message may appear for each period, until
they are sent to the linked destination.
The Frequency of an event message may range between 2 and 20. The Period is indicated in hours,
ranging between 1 and 672. The longest time period corresponds to 28 days or 4 weeks.
Table 93: Example of event table
Event type Frequency Time period
Total synchronization loss 10 1
In this example an event message is sent to the message destinations if there is a Total synchronization
loss event message when the system generates the event message 10 times within 1 hour.
6.5.1.3 Signal destinations
After a first start, all event tables are exactly assigned to a message destination. (Exception: Local
destination and SNMP destination use this event table.) You can assign event tables to several or no
message destinations
The destinations are configured in the Message destinations view.
6.5.1.3.1 Signal destination system phone 1 and 2
Event messages are sent to all system phones with display and entered in the corresponding message
group.
• Destination system phone 1:
• By default allocated to event table 1, which is preconfigured for common use.
• Fix allocated to message group 16.
• Destination system phone 2:
• By default allocated to event table 8, which is preconfigured for front desk terminals in hospitality
environments.
• Fix allocated to message group 15.
6.5.1.3.2 External signal destinations
Depending on the event table allocated, event messages (normally Table 2) are sent to a specified external
signal destination. Two external signal destinations can be specified:
Release 7.1
System Manual for Mitel SMB Controller 254
