Expansion Stages and System Capacity
Table 12: Front panel
Interfaces SMBC Note
FXS terminal interfaces 6 RJ45 socket (FXS1...FXS6)
Ethernet interfaces 1Gbit/s
(LAN)
4
4
RJ45 socket (Eth0...Eth3)
RJ45 sockets on front panel for
interface cards
16 RJ45 socket (x.1...x.4)
RJ45 sockets on front panel, not
usable
2 RJ45 socket, not wired
Supply input 1 2-pin supply socket
Pilot key 1
LED display 1 LED PWR, LED F0 - F6, LED
SYS
The diagram below shows the position of all the interfaces and slots on the mainboard display and control
elements and on the front panel.
4
Only 1 interface (eth0) is usable for MiVoice Office 400
Release 7.1
41 System Manual for Mitel SMB Controller
