18.3.5. Movement of parts
Parts can be moved.
(1) Click the part to move to select it (<a>).
(2) After the "Edit menu" window is displayed, click the [Move] button (<b>).
(3) Click the position (block) where the part is moved to.
At this time, the current position (block) of part is red, and the position (block) where the part is moved onto is
green.
A move confirmation message will be displayed. Click the [Yes] button.
Figure 18-45 Movement of parts
<a>
<b>
<c>
A move confirmation massage is displayed
when you click a move destination.
