18-453 18-453
Table 18-12 The file which cannot be operated on a file management screen, and its extension
No. Files
Trap function log files(program execution log files)
Servo data log files
(This file is reconstructed at power supply ON.)
Force control log file
(This file is deleted at power supply OFF.)
Error record log files
System files
(Backup information etc.)
Serial information file
(This file is created at the time of backup)
18.4.2. Copy
This copies the files.
Select t the transmission source file names from the list at left, and designate the transmission destination folder
on the right side. Multiple transmission source files can be selected at the same time.
Click the [Copy] button after choosing the file(s) to copy and setting up the transmission destination. The file is
copied after copy confirmation message display.
When the file of the same name exists in the transmission destination, an overwrite confirmation message is
displayed.
18.4.3. Delete
This deletes the files.
Select the file(s) to delete in the list. It is possible to select multiple files at the same time. All the files selected in
the left and right lists are deleted. Click the [Delete] button after selecting the files in the lists. A deletion
confirmation message is displayed.
18.4.4. Rename
This renames the files.
Select a file in the list. It is possible to select a file from both lists. Click the [Rename] button, and input the new
file name in the “Setup for Rename” dialog.
Figure 18-57 Setup for Rename
To Next Page
