21-578 21-578
21.13. Types of Robot Model
You can select the robot model to be displayed on the 3D monitor from "detailed model" and "simple model".
Note, however, that the "detailed model" sometimes is not displayed depending on the model.
As the default setting, "detailed model" is displayed.
To change the type of robot model, select the type of robot model to displayed in the [3D view] tab -> [Robot
model] group on the ribbon.
Also, the type of robot model becomes "simple model" with the "The robot of 3D monitor is displayed in simple
model." checkbox selected in the New Workspace screen.
Figure 21-104 Types of Robot Model
The recommended environment for displaying a "detailed model" is as follows.
Dual core including Core2 Duo or Core i3 3 GHz or faster processor
The 3D monitor sometimes cannot display detailed models normally and
functions such as the operation panel are obstructed if they are displayed
on a PC that does not satisfy this recommended environment. In this case,
change the model type to simple model.
