11 - 23
11.1 Scan Time
11.1.3 Factors that increase the scan time
11
CPU MODULE PROCESSING TIME
(5) Use of file registers
When a file register is used, the processing time shown in Table 11.25 occurs when
[Use the same file name as the program.] is selected in the parameter setting.
When [Use the following file.] is selected, the scan time will not be prolonged.
* 1 : n indicates the number of program files.
Table11.25 Processing time taken when file registers are used
CPU module Processing time
Standard RAM
Q02CPU 1.03ms
Q02HCPU, Q06HCPU, Q12HCPU, Q25HCPU,
Q02PHCPU, Q06PHCPU, Q12PHCPU,
Q25PHCPU, Q12PRHCPU, Q25PRHCPU
0.41ms
Q02UCPU 0.082ms
Q03UDCPU, Q03UDECPU 0.043ms
Q04UDHCPU, Q06UDHCPU, Q13UDHCPU,
Q26UDHCPU, Q04UDEHCPU, Q06UDEHCPU,
Q13UDEHCPU, Q26UDEHCPU
0.041ms
SRAM card
Q02CPU
1.14 n ms
*1
Q02HCPU, Q06HCPU, Q12HCPU, Q25HCPU,
Q02PHCPU, Q06PHCPU, Q12PHCPU,
Q25PHCPU, Q12PRHCPU, Q25PRHCPU
0.50 n ms
*1
Q02UCPU
0.11 n ms
*1
Q03UDCPU, Q03UDECPU
0.06 n ms
*1
Q04UDHCPU, Q06UDHCPU, Q13UDHCPU,
Q26UDHCPU, Q04UDEHCPU, Q06UDEHCPU,
Q13UDEHCPU, Q26UDEHCPU
0.06 n ms
*1
To Next Page
