DEVICE EXPLANATION
10 - 47
10.2 Internal User Devices
10.2.14 Link special register (SW)
10.2.14 Link special register (SW)
(1) Definition
Link special registers are used to store data on the communication status and errors
of an intelligent function module such as CC-Link IE controller network module and
MELSECNET/H network module.
Because the data link information is stored as numeric data, the link special registers
serve as a tool for identifying the locations and causes of faults.
(2) Number of link special register points
The number of link special register points is as described in Table10.9.
Table10.9 Number of link special register points of each CPU module
CPU module Number of link special relay points
Basic model QCPU
1024 points (SW0 to 3FF).
512 points assigned to each intelligent function module such as
CC-Link IE controller network module and MELSECNET/H
network module.
High Performance
model QCPU
Process CPU
Redundant CPU
2048 points (SW0 to 7FF).
512 points assigned to each intelligent function module such as
CC-Link IE controller network module and MELSECNET/H
network module.
The link special registers can be assigned as shown below.
SW200
SW3FF
SW400
SW5FF
SW600
SW7FF
SW0
to
to
to
to
SW1FF
Link special register
For the 1st network
module
For the 2nd network
module
For the 3rd network
module
For the 4th network
module
2048
points
512
points
512
points
512
points
512
points
