Mitsubishi Q02CPU

8
- 32
8.3 Network Parameters
8
PARAMETERS
8.3 Network Parameters
This section explains the network parameter list and parameter details.
mn, M and N in the Parameter No. field of this section
mn, M and N in the Parameter No. field of this section indicate the following.
Mn : Indicates a "start I/O No. 16" value.
** : Indicates any value.
N : Indicates the module number.
M : Indicates the network type.
Table8.27 In the case of MELSECNET/H, Ethernet setting ( (1), (2) in this section)
M Network type
1
H
MELSECNET/10 mode (Control station), MELSECNET/H mode (Control station)
2
H
MELSECNET/10 mode (Normal station), MELSECNET/H mode (Normal station)
5
H
MELSECNET/H (Remote master)
A
H
MELSECNET/H (Standby station)
B
H
MELSECNET/H mode multiplexed remote I/O network master station
D
H
MELSECNET/H mode multiplexed remote I/O network sub-master station
(When there is no parameter setting)
E
H
MELSECNET/H mode multiplexed remote I/O network sub-master station
(When there is parameter setting)
Table8.28 In the case of CC-Link setting ( (3) in this section)
M Network type
0
H
Master station
1
H
Local station
2
H
Standby master station
