6.4 Setting of Output (Y) Status when Changing between STOP and
RUN
(1) Definition
When changed from the RUN or other status to the STOP status, the CPU module
stores the output (Y) in the RUN status into the PLC and turns all outputs (Y) OFF.
The status after transition from STOP to RUN can be selected from the following two
options with the CPU module.
• The output (Y) status prior to STOP is output.
• The output is cleared.
(2) Setting applications
Using a holding circuit or similar, it is possible to select whether the output is resumed
from the previous status or not when the STOP status is changed to the RUN status.
• When the output (Y) status prior to STOP is set to output
• When output (Y) is set to clear
Diagram 6.5 Holding circuit
Diagram 6.6 Timing chart when output (Y) status prior to STOP is set to output
Diagram 6.7 Timing chart when output (Y) is set to clear
Start
button
Stop
button
OFF
ON
ON
ON
OFF
X21
Y
0
X20
RUN RUN
STOP
STOP
OFF
ON
ON
ON
OFF
X21
Y
0
X20
RUN RUN
STOP
STOP
