6 - 74
6.11 Monitor Function
6.11.4 Executional conditioned device test
6
FUNCTIONS
2) When the Online change (Write during RUN) is executed during
execution of the Executional conditioned device test
The Online change completes normally. If executional conditioned device test
setting has been registered in the program to be changed online, the
corresponding setting will be disabled. ( (5)(e) in this section)
(e) Online change (Write during RUN) of the CPU module with Executional
conditioned device test registration
1) Online change in ladder mode
If executional conditioned device test setting has been registered in the ladder
block to be changed online, the CPU module disables the corresponding
setting.
[Example 1]
Step numbers of registrations 1 to 3 are specified in the executional
conditioned device test settings. When the ladder block including the
registration 2 is changed and the Online change (Write during RUN) is
executed, the registration 2 is disabled during execution of the Online change.
Since the registrations 1 and 3 are not included in the change target program,
they are not disabled.
Figure 6.48 Executing Online change for a ladder block
