Mitsubishi Q02CPU

App
- 27
Appendix 1 Special Relay List
APPENDICES
(15)Redundant power supply module information
*1: The "power supply 1" indicates the redundant power supply module (Q64RP) mounted on the POWER 1 slot of the redundant base unit (Q38RB/68RB).
The "power supply 2" indicates the redundant power supply module (Q64RP) mounted on the POWER 2 slot of the redundant base unit (Q38RB/68RB).
TableApp.15 Special relay
Number Name Meaning Explanation
Set by
(When Set)
Correspon
ding host
SM *2
Corresponding CPU
SM1747
Transmission trigger
end flag
OFF : Transmission
uncompleted
ON : Transmission end
SM1747 Block 36
<In the case of Q4AR>
Turns ON only during one
scan when the transmission
of the corresponding data is
completed.
<In the case of QnPRH>
Turns ON only during one
scan when the transmission
of the corresponding block is
completed.
S (status change) New
Q4AR
QnPRH
SM1748 SM1748 Block 37
SM1749 SM1749 Block 38
SM1750 SM1750 Block 39
SM1751 SM1751 Block 40
SM1752 SM1752 Block 41
SM1753 SM1753 Block 42
SM1754 SM1754 Block 43
SM1755 SM1755 Block 44
SM1756 SM1756 Block 45
SM1757 SM1757 Block 46
SM1758 SM1758 Block 47
SM1759 SM1759 Block 48
SM1760 SM1760 Block 49
SM1761 SM1761 Block 50
SM1762 SM1762 Block 51
SM1763 SM1763 Block 52
SM1764 SM1764 Block 53
SM1765 SM1765 Block 54
SM1766 SM1766 Block 55
SM1767 SM1767 Block 56
SM1768 SM1768 Block 57
SM1769 SM1769 Block 58
SM1770 SM1770 Block 59
SM1771 SM1771 Block 60
SM1772 SM1772 Block 61
SM1773 SM1773 Block 62
SM1774 SM1774 Block 63
SM1775 SM1775 Block 64
TableApp.16 Special relay
Number Name Meaning Explanation
Set by
(When Set)
Correspon
ding host
SM *2
Corresponding CPU
SM1780
Power supply off
detection flag
OFF : No redundant power
supply module with
input power OFF
detected
ON : Redundant power
supply module with
input power OFF
detected
• Turns ON when one or more redundant power
supply modules with input power OFF are detected.
• SM turns on if single bit of SD1780 is on.
• SM turns off if all bits of SD1780 are off.
• This relay turns OFF when the main base unit is not
the redundant main base unit (Q38RB).
S (Each END)
New QnPRH
SM1781
Power supply module
failure detection flag
OFF : No faulty redundant
power supply module
detected
ON : Faulty redundant
power supply module
detected
• Turns ON when one or more faulty redundant power
supply modules are detected.
• SM turns on if single bit of SD1781 is on.
• SM turns off if all bits of SD1781 are off
• This relay turns OFF when the main base unit is not
the redundant main base unit (Q38RB).
S (Each END)
SM1782
Momentary power
failure for power
supply moduleÇP *1
detection flag
OFF : No momentary power
failure detected
ON : Momentary power
failure detected
• Turns ON when a momentary power failure of the
input power supply to the power supply 1 or 2 is
detected one or more times. After turning ON,
remains ON if the power supply recovers from the
momentary power failure.
• Turns OFF the flag (SM1782, SM1783) of the power
supply 1/2 when the CPU module starts.
• This relay turns OFF when the input power to either
redundant power supply module switches OFF.
• This relay turns OFF when the main base unit is not
the redundant main base unit (Q38RB).
S (Each END)
SM1783
Momentary power
failure for power
supply module2 *1
detection flag
