6.1 Function List
6
FUNCTIONS
CHAPTER6 FUNCTIONS
Function of CPU module is as follows:
6.1 Function List
Functions of CPU module are listed in Table6.2.
The Nos. in the "CPU module" field correspond to the CPU modules as indicated below.
: Available : N/A
(Continued on next page)
Table6.1 Nos. in "CPU module" field and the corresponding CPU modules
No. CPU module
1) Basic model QCPU
2) High Performance model QCPU
3) Process CPU
4) Redundant CPU
Table6.2 CPU module function list
Item Description
CPU module
Reference
section
1) 2) 3) 4)
Constant scan
This function executes the program in a set time interval
regardless of the program scan time.
Section 6.2
Latch function
This function maintains the device data when
performing the reset operation during power off.
Section 6.3
Output status selection function for
transition from STOP status to RUN
status
This function selects the output Y status (output before
STOP/output after the calculation execution) when the
CPU module is set from STOP status to RUN status.
Section 6.4
Clock function This function executes the CPU module internal clock. Section 6.5
Remote RUN/STOP
This function stops and starts operating the CPU
module.
Section
6.6.1
Remote PAUSE
This function stops the CPU module operation while
retaining the output (Y) of the CPU module.
Section
6.6.2
Remote RESET
This function resets the CPU module when the CPU
module is in a STOP status.
Section
6.6.3
Remote latch clear
This function clears the latch data of the CPU module
when the CPU module is in a STOP status.
Section
6.6.4
Input response time selection
This function selects the response time of the Q series
input module, I/O combined module, high speed input
module or interrupt module.
Section 6.7
