A
- 16
(Related manual).................QCPU User's Manual (Hardware Design, Maintenance and Inspection)
CONTENTS
CHAPTER1 OVERVIEW
1.1 Features
CHAPTER2 SYSTEM CONFIGURATION
2.1 System Configuration
2.1.1 System Configuration for Single CPU System
2.1.2 System Configuration for Bus connection of GOT
2.1.3 Configuration of peripheral devices
2.1.4 Applicable Devices and Software
2.1.5 Precaution on system configuration
2.2 Confirming Serial No. and Function Version
CHAPTER3 GENERAL SPECIFICATIONS
CHAPTER4 HARDWARE SPECIFICATIONS OF THE CPU MODULE
4.1 Performance Specifications
4.2 Basic Model QCPU
4.2.1 Part Names
4.2.2 Switch Operation After Writing Program
4.2.3 Reset Operation
4.2.4 Latch Clear Operation
4.3 High Performance Model QCPU, Process CPU and Redundant CPU
4.3.1 Part Names
4.3.2 Switch Operation After Writing Program
4.3.3 Reset Operation
4.3.4 Latch Clear Operation
4.3.5 Automatic Writing to Standard ROM
CHAPTER5 POWER SUPPLY MODULE
5.1 Base Units and CPU Modules Used with Power Supply Module
5.2 Specifications
5.2.1 Power supply module specifications
5.2.2 Selecting the power supply module
5.2.3 Precaution when connecting the uninterruptive power supply
5.2.4 Cautions on power supply capacity
5.3 Names of Parts and Settings
CHAPTER6 BASE UNIT AND EXTENSION CABLE
6.1 Base Unit
