Appendix 3 Comparison
The Q series CPU module has been upgraded with new functions and specifications.
The functions and specifications that can be used with the CPU module change
depending on the function version/serial No..
Appendix 3.1 Basic model QCPU Upgrade
(1) Specification comparison
: Usable/compatible, : Unusable/incompatible
TableApp.37 Specification comparison
Specifications
Function Version
Function Version A
First 5 digits of serial No. are
"04121" or earlier
Function Version B
First 5 digits of serial No. are
"04122" or later
Standard RAM capacity
Q00JCPU
Q00CPU 64k bytes 128k bytes
Q01CPU 64k bytes 128k bytes
CPU shared memory
