1.1 Features
1.1.2 Features of High Performance model QCPU
1
OVERVIEW
1.1.2 Features of High Performance model QCPU
The features specific to the High Performance model QCPU are described below.
(1) High performance and large capacity
The High Performance model QCPU is a module targeted for small-scaled to large-
scaled systems and capable of high-speed massive data processing.
The High Performance model QCPU realizes construction of the optimum and high-
performance system.
Diagram 1.3 System example using the High Performance model QCPU
Ethernet
MELSECNET remote I/O network
MELSECNET/H PLC to PLC network
High Performance model QCPU
CC-Link remote
I/O station
CC-Link remote
device station
GX Developer
