PROCEDURE FOR WRITING PROGRAM TO CPU
MODULE
11.2 High Performance Model QCPU, Process CPU, Redundant CPU
11.2.3 Procedure for writing one program
11
- 10
9
Device Explanation
10
CPU Module Processing Time
11
Procedure for Writing Program to CPU Module
AppendicesIndex
11.2.3 Procedure for writing one program
This section explains the procedure for writing the parameters and program created by GX
Developer to the High Performance model QCPU, Process CPU or Redundant CPU.
This section explains the procedure for writing a program to the program memory
( Section 5.2.2).
When storing the program into the standard ROM or memory card and executing boot run,
perform the procedure given in this section, and then carry out the procedure given in Sec-
tion 11.2.5.
In the following procedure, indicates the operation on the GX Developer side, and
indicates that on the High Performance model QCPU, Process CPU or Redundant CPU
side.
............
Start
Start GX Developer.
Set the project.
Change the number of device points in
device setting of PLC parameter.
Create a program to be executed in the
CPU module.
GX Developer Operating Manual
Section 9.2
Ladder (write) screen
Do you
change the number
of device points
used?
NO
YES
1)
