Mitsubishi Q02CPU

8
PARAMETERS
8.3 Network Parameters
8
- 33
1
Overview
2
Performance Specification
3
Sequence Program Configuration and Execution Conditions
4
I/O Nunber Assignment
5
Memories and Files Handled by CPU Module
6
Functions
7
Communication with Intelligent Function Module
8
Parameters
(1) MELSECNET/H setting
Set the MELSECNET/H network parameters.
* 1 : Can be set only when the Redundant CPU is used.
* 2 : Can be set only when the Process CPU or Redundant CPU is used.
Diagram 8.26 Network parameters Setting the number of MNET/10H Ethernet cards. (for
MELSECNET/H setting)
Table8.29 MELSECNET/H setting list
Item Parameter No. Description Setting range Default value Reference
Nunber of MELSECNET 5000H
Set the MELSECNET/H network
parameters.
Refer to the Q Corresponding
MELSECNET/H Manual.
---- ----
Starting I/O No.
5NM0
HNetwork No.
Total stations
Group No. 05mn
H
Mode 5NM0H
Refresh parameters 5NM1
H
Setup Common
parameters
5NM2
H
Station inherent
parameters
5NM3
H
Sub-master parameters
*2
5NM5
H
Setup Common
parameters 2
5NMA
H
Station inherent
parameters 2
5NMB
H
Interrupt settings
Group setting
*1
D004
H
Redundant settings
*1
D5**
H
Valid module during other
station access
5001
H
Interlink transmission
parameters
5002
H
Routing parameters 5003
H
