Mitsubishi Q02CPU

App
- 35
Appendix 2 Special Register List
APPENDICES
Remark
*6 : Extensions are shown in TableApp.19.
TableApp.19 Extension name
SDn SDn+1
Extension
name
File type
Higher8 bits Lower8 bits Higher8 bits
51H 50H 41H QPA Parameters
51H 50H 47H QPG Sequence program/SFC program
51H 43H 44H QCD Device comment
51H 44H 49H QDI
Device initial value
(Other than the Basic model QCPU)
51H 44H 52H QDR File register
51H 44H 53H QDS
Simulation data
(Other than the Basic model QCPU)
51H 44H 4CH QDL
Local device
(Other than the Basic model QCPU)
51H 54H 53H QTS Sampling trace data (For QnA)
51H 54H 4CH QTL Status latch data (For QnA)
51H 54H 50H QTP Program trace data (For QnA)
51H 54H 52H QTR
SFC trace file
(Other than the Basic model QCPU)
51H 46H 44H QFD
Trouble history data
(Other than the Basic model QCPU)
