9
DEVICE EXPLANATION
9.2 Internal User Devices
9.2.10 Timer (T)
9
- 28
9
Device Explanation
10
CPU Module Processing
Time
11
Procedure for Writing
Program to CPU Module
AppendicesIndex
(7) Timer Processing and accuracy
(a) Processing method
When an OUT T instruction is executed, the following is processed: timer coil
ON/OFF, current value update and contact ON/OFF processing. Timer current
value update and contact ON/OFF processing are not performed at END
processing.
Diagram 9.24 Processing at execution of OUT TO instruction
X0
T0
K10
END OUT T0 END
[Processing at execution of OUT T0 instruction]
[Ladder example]
Sequence
program
Processing content
Coil ON/OFF
Current value update
Contact ON/OFF
To Next Page
