PERFORMANCE SPECIFICATION
* 8 : The step relays are devices for the SFC function.
* 9 : Value including those of the CPU module and base unit.
* 10 : Value including those of the CPU module, base unit and power supply module.
Table2.1 Performance Specification
Item
Basic model QCPU High Performance model QCPU
Q00JCPU Q00CPU Q01CPU Q02CPU Q02HCPU Q06HCPU
Number of device points
Link special relay [SB] 1024 points(SB0 to 3FF) 2048 points(SB0 to 7FF)
Link special register [SW] 1024 points(SW0 to 3FF) 2048 points(SW0 to 7FF)
Step relay [S]
*8
2048 points(S0 to 127/block) 8192 points(S0 to 8191)
Index register [Z] 10 points(Z0 to 9) 16 points(Z0 to 15)
Pointer [P] 300 points(P0 to 299)
4096 points (P0 to 4095), set parameter values to select
usable range of in-file pointer / shared pointers.
Interrupt pointer [ I ]
128 points(I0 to 127)
The specified intervals of the system interrupt pointers
I28 to 31 can be set with parameters.
(2 to 1000ms, 1ms unit)
Default I28 : 100ms I29 : 40ms I30 : 20ms I31 : 10ms
256 points(I0 to 255)
The specified intervals of the system interrupt pointers
I28 to I31 can be set with parameters.
(0.5 to 1000ms, 0.5 ms/unit)
Default I28 : 100ms I29 : 40ms I30 : 20ms I31 : 10ms
Special relay [SM] 1024 points(SM0 to 1023) 2048 points(SM0 to 2047)
Special register [SD] 1024 points(SD0 to 1023) 2048 points(SD0 to 2047)
Function input [FX] 16 points(FX0 to F)
Function output [FY] 16 points(FY0 to F)
Function register[FD] 5 points(FD0 to 4)
Number of device tracking words ----
Link direct device
Device having a direct access to link device.MELSECNET/10(H) use only.
Specified form :J \X ,J \Y ,J \W ,J \B ,J \SW ,
J\SB
Intelligent function module device
Device having a direct access to the buffer memory of the intelligent function module.
Specified form : U \G
Latch (power failure compensation) range
L0 to 2047 (default)
(Latch range can be set for B, F, V, T, ST, C, D, and W.)
L0 to 8191 (default)
(Latch range can be set for B, F, V, T, ST, C, D, and W.)
RUN/PAUSE contact
RUN and PAUSE contacts can be set from among X0 to
7FF, respectively.
RUN and PAUSE contacts can be set from among X0 to
1FFF, respectively.
Clock function
Year, month, day, hour, minute, second, day of the week
(leap year automatic distinction)
Accuracy -3.2 to +5.27s (TYP. +1.98s) /d at 0
Accuracy -2.57 to +5.27s(TYP. +2.22s)/d at 25
Accuracy -11.68 to +3.65s(TYP. -2.64s)/d at 55
Year, month, day, hour, minute, second, day of the week
(leap year automatic distinction)
Accuracy -3.18 to +5.25s (TYP. +2.12s) /d at 0
Accuracy -3.93 to +5.25s(TYP. +1.90s)/d at 25
Accuracy -14.69 to +3.53s(TYP. -3.67s)/d at 55
Allowable momentary power failure period
Within 20ms
(100VAC or
more)
Varies according to the type of power supply module.
5VDC internal current consumption
0.22A
*9
0.25A 0.27A 0.60A 0.64A
External dimensions
H 98mm 98mm
W
245mm
*10
27.4mm
D 97.5mm 89.3mm
Weight
0.66kg
*10
0.13kg 0.13kg 0.20kg
