PERFORMANCE SPECIFICATION
2
- 6
1
Overview
2
Performance Specification
3
Sequence Program Configuration and Execution Conditions
4
I/O Nunber Assignment
5
Memories and Files Handled by CPU Module
6
Functions
7
Communication with Intelligent Function Module
8
Parameters
High Performance model QCPU Process CPU Redundant CPU
Remark
Q12HCPU Q25HCPU Q12PHCPU Q25PHCPU Q12PRHCPU Q25PRHCPU
Default 8192 points (M0 to 8191) (changeable)
The number of used points can
be changed within the setting
range. ( Section 9.2)
Default 8192 points (L0 to 8191) (changeable)
Default 8192points (B0 to 1FFF) (changeable)
Default 2048 points (T0 to 2047) (for low / high speed timer) (changeable)
Use the instruction to switch between the low speed timer and high speed timer.
The measurement unit of the low / high speed timer is set with parameters.(Low speed timer: 1 to 1000ms,
1ms/unit, default 100ms)(High speed timer: 0.1 to 100ms, 0.1ms/unit, default 10ms)
Default 0 point(for low / high speed retentive timer) (changeable)
Use the instruction to switch between the low speed retentive timer and high speed retentive timer.
The measurement unit of the low /high speed retentive timer is set with parameters.(Low speed retentive timer :
1 to 1000ms, 1ms/unit, default 100ms)(High speed retentive timer : 0.1 to 100ms, 0.1ms/unit, default 10ms)
• Normal counter default 1024 points (C0 to 1023) (changeable)
• Interrupt counter maximum 256 points(default 0 point, set with parameters)
Default 12288 points (D0 to 12287) (changeable)
Default 8192 points (W0 to 1FFF) (changeable)
Default 2048 points (F0 to 2047) (changeable)
Default 2048 points (V0 to 2047) (changeable)
• When a standard RAM is used: The number of points of up to 131072 points can be used by block conversion in
increments of 32768 points (R0 to 32767)
• When a SRAM card (1Mbyte) is used:The number of points of up to 517120 points can be used by block conversion in
increments of 32768 points (R0 to 32767).
• When a SRAM card (2Mbyte) is used:The number of points of up to 1041408 points can be used by block conversion in
increments of 32768 points (R0 to 32767).
• When a Flash card (2Mbyte) is used:The number of points of up to 1041408 points can be used by block conversion in
increments of 32768 points (R0 to 32767).
• When a Flash card (4Mbyte) is used:The number of points of up to 1042432 points can be used by block conversion in
increments of 32768 points (R0 to 32767).
• When the Basic model QCPU
is used:
The number of device points
is fixed.
• When High Performance
model QCPU, Process CPU
or Redundant CPU is used:
When a Flash card is used,
read only is possible.The ATA
card cannot be used.
• When a standard RAM is used: 131072 points (ZR0 to 131071), No block conversion necessary.
• When a SRAM card (1Mbyte) is used:517120 points (ZR0 to 517119), No block conversion necessary.
• When a SRAM card (2Mbyte) is used:1041408 points (ZR0 to 1041407), No block conversion necessary.
• When a Flash card (2Mbyte) is used:1041408 points (ZR0 to 1041407), No block conversion necessary.
• When a Flash card (4Mbyte) is used:1042432 points (ZR0 to 1042431), No block conversion necessary.
