Mitsubishi Q02CPU

2
- 5
2
PERFORMANCE SPECIFICATION
Table2.1 Performance Specification
Item
Basic model QCPU High Performance model QCPU
Q00JCPU Q00CPU Q01CPU Q02CPU Q02HCPU Q06HCPU
Number of device points
Internal relay [M] Default 8192 points (M0 to 8191) (changeable)
Latch relay [L] Default 2048 points (L0 to 2047) (changeable) Default 8192 points (L0 to 8191) (changeable)
Link relay [B] Default 2048 points (B0 to 7FF) (changeable) Default 8192points (B0 to 1FFF) (changeable)
Timer [T]
Default 512 points (T0 to 511) (changeable)
(for low / high speed timer)
Default 2048 points (T0 to 2047) (changeable)
(for low / high speed timer)
Use the instruction to switch between the low speed timer and high speed timer.
The measurement unit of the low / high speed timer is set with parameters.(Low speed timer: 1 to 1000ms, 1ms/
unit, default 100ms)(High speed timer: 0.1 to 100ms, 0.1ms/unit, default 10ms)
Retentive timer [ST]
Default 0 point(for low / high speed retentive timer) (changeable)
Use the instruction to switch between the low speed retentive timer and high speed retentive timer.
The measurement unit of the low /high speed retentive timer is set with parameters.(Low speed retentive timer : 1
to 1000ms, 1ms/unit, default 100ms)(High speed retentive timer : 0.1 to 100ms, 0.1ms/unit, default 10ms)
Counter [C]
• Normal counter default 512 points (C0 to 511)
(changeable)
• Interrupt counter maximum 128 points(default 0 point,
set with parameters)
• Normal counter default 1024 points (C0 to 1023)
(changeable)
• Interrupt counter maximum 256 points(default 0 point,
set with parameters)
Data register [D] Default 11136 points (D0 to 11135) (changeable) Default 12288 points (D0 to 12287) (changeable)
Link register [W] Default 2048 points (W0 to 7FF) (changeable) Default 8192 points (W0 to 1FFF) (changeable)
Annunciator [F] Default 1024 points (F0 to 1023) (changeable) Default 2048 points (F0 to 2047) (changeable)
Edge relay [V] Default 1024 points (V0 to 1023) (changeable) Default 2048 points (V0 to 2047) (changeable)
File register
[R] ----
32768 points(R0 to 32767)
/block
• When a standard RAM is used:
Q02CPU••••••••••••32768 points (R0 to 32767)
Q02HCPU,Q06HCPU••••••••••••The number of points
of up to 65536 points can be used by block
conversion in increments of 32768 points (R0 to
32767).
• When a SRAM (1M byte) card is used:
The number of points of up to 517120 points can be
used by block conversion in increments of 32768
points (R0 to 32767).
• When a SRAM (2M byte) card is used:
The number of points of up to 1041408 points can be
used by block conversion in increments of 32768
points (R0 to 32767).
• When a Flash (2M byte) card is used:
The number of points of up to 1041408 points can be
used by block conversion in increments of 32768
points (R0 to 32767).
• When a Flash (4M byte) card is used:
The number of points of up to 1042432 points can be
used by block conversion in increments of 32768
points (R0 to 32767).
[ZR] ---- 65536 points(ZR0 to 65535)
• When a standard RAM is used:
Q02CPU•••••••••••••32768 points (R0 to 32767)
Q02HCPU,Q06HCPU••••65536 points (R0 to 65535),
no block conversion necessary.
• When a SRAM (1M byte) card is used:
517120 points (ZR0 to 517119), no block conversion
necessary.
• When a SRAM (2M byte) card is used:
1041408 points (ZR0 to 1041407), no block
conversion necessary.
• When a Flash (2M byte) card is used:
1041408 points (ZR0 to 1041407), no block
conversion necessary.
• When a Flash (4M byte) card is used:
1042432 points (ZR0 to 1042431), no block conversion
necessary.
