10.1 Scan Time
10.1.2 Time required for each processing included in scan time
10
- 11
9
Device Explanation
10
CPU Module Processing Time
11
Procedure for Writing Program to CPU Module
AppendicesIndex
(b) High Performance model QCPU, Process CPU, Redundant CPU
• Monitor by GX Developer
This indicates the processing time required to execute monitor by GX
Developer.
(8) Low speed program operation time
Note10.6
Note6
The low speed program operation time is the sum of processing times of the
instructions used in the low speed execution type program to be executed by the CPU
module.
The processing times are the same as those in (4) of this section.
(9) Common processing time
This indicates the processing time common to the CPU modules.
Table10.15 shows the common processing time for each CPU module model.
Table10.13 When 32 points of data registers have been set in device registration monitor
CPU module Processing time
Q02CPU 0.017ms
Q02HCPU, Q06HCPU, Q12HCPU, Q25HCPU,
Q12PHCPU, Q25PHCPU, Q12PRHCPU,
Q25PRHCPU
0.011ms
Table10.14 When monitor condition has been set
CPU module
Processing time
Specified step match
Specified device
match
Q02CPU 0.05ms 0.01ms
Q02HCPU, Q06HCPU, Q12HCPU, Q25HCPU,
Q12PHCPU, Q25PHCPU, Q12PRHCPU,
Q25PRHCPU
0.03ms 0.01ms
Note6
Table10.15 Common processing time
CPU module Common processing time
Q00JCPU 0.66ms
Q00CPU 0.60ms
Q01CPU 0.52ms
Q02CPU 0.38ms
Q02HCPU, Q06HCPU, Q12HCPU, Q25HCPU,
Q12PHCPU, Q25PHCPU
0.15ms
Q12PRHCPU, Q25PRHCPU 0.5ms
Basic
Redundant
Note10.6
Since the Basic model QCPU and Redundant CPU cannot use low speed execution type
programs, it is not necessary to be conscious of the low speed execution type program operation
time.
Basic
Note10.6
Redundant
