I/O NUMBER ASSIGNMENT
4.4 Base Unit Assignment (Base Mode)
4
- 13
1
Overview
2
Performance Specification
3
Sequence Program Configuration and Execution Conditions
4
I/O Nunber Assignment
5
Memories and Files Handled by CPU Module
6
Functions
7
Communication with Intelligent Function Module
8
Parameters
(d) For 12-slot base unit: 12 slots are occupied
Diagram 4.12 For 12-slot base units
Power supply
module
CPU module
Main base unit
Slot number
CPU 0 1 2 3 4 5 6 7 8 9 10 11
Extension base unit
Q312B
Q612B
12 13 14 15 16 17 18 19 20 21 22 23
