Mitutoyo ID-C Series User Manual

94
10Specications
No. 99MAH056A
Model No. ID-C0512MNX ID-C0512MNXB ID-C0512ENX ID-C0512ENXB
Code No. 543-701 543-701B 543-702 543-702B
Measuring
range
12.7 mm/0.5 in
Resolution 0.0005 mm/0.00002 in
Resolution
switching
0.0005/0.001/0.01 mm
0.00002/0.00005/0.0001/0.0005 in
Error of
indication
for the total
measuring
range
(MPE
E
)
*1
0.003 mm/±0.00012 in
Hysteresis
(MPE
H
)
*1
0.002 mm/0.0001 in
Repeatability
(MPE
R
)
*1
0.002 mm/0.0001 in
Stem ø8 mm 0.375 in diameter (ø9.52 mm)
Contact point
Carbide (M2.5 x 0.45)
Part No. 901312 (standard
accessory)
Carbide (No. 4-48UNF)
Part No. 21BZB005 (standard
accessory)
Measuring
force (MPL)
1.5 N or less
Measurement
direction
All directions
Backs With lug Flat With lug Flat
Mass 175 g 165 g 195 g 165 g
