Mitutoyo ID-C Series User Manual

50
5 Setting Parameters
No. 99MAH056A
(Short press) / (Long press)
5.7
Setting Calculation Function Selection and
CalculationCoe󰀩cient
In addition to normal measurement, this product can also perform calculation
measurement, in which results are displayed by multiplying the plunger
movementamountbyacalculationcoe󰀩cient.
Tips
Using the calculation function, the movement amount of the plunger can be calculated
anddisplayedasaradiusdi󰀨erenceasshownbelow.
Inthegurebelow,thecalculationcoe󰀩cient(A)isasfollows.
R=Ax A=
–
sin
θ
/2
=
–
sin 60°
=
–
6.4641
1 - sin
θ
/2 1 - sin 60°
θ (120°)
R
