21
No. 99MAH056A
4 Measurement Method
(Short press) / (Long press)
4
Measurement Method
4.1
Absolute Measurement (ABS)
Sets (presets) the measurement origin and measures the dimensions of the
workpiece.
NOTICE
When setting or presetting the origin, be sure to lift the plunger at least 0.2 mm from
the bottom of the stroke.
0.2 mm or
more
