40
5 Setting Parameters
No. 99MAH056A
(Short press) / (Long press)
5.2
Selecting Measurement Mode
The measurement mode can be selected from "Standard 1", "Standard 2" and
"Peak Detection".
2 31
F3
F1
F2
F3
F1
F2
F1
F3
Standard 1
Peak detection
Standard 2
Go to the
next item
1 Press the [F2] key.
» Measurement mode can be set.
2 Press the [F1] key or [F3] key to set the measurement mode.
» Each time the key is pressed, it will switch the measurement mode in order.
3 Press the [F2] key.
» Settingsareconrmed;shiftstothenextparameteritem.
(Go to "5.3 Selecting Unit System" on page 41.)
Tips
Standard(1,2)andpeakdetectionhavedierentfunctionassignmentswhen
respective key ([F1] key, [F2] key, [F3] key) is short pressed.
Measurement mode [F1] key [F2] key [F3] key
Standard 1
Customizable
(Initial settings: "N/A", "Zero setting", "Data hold")
Standard 2 Unit switching Zero setting Data hold
Peak detection
Peak detection
display switching
Peak detection
start
Data hold
To Next Page
