Mitutoyo ID-C Series User Manual

25
No. 99MAH056A
4 Measurement Method
(Short press) / (Long press)
4.2
Incremental Measurement (INC)
Zeros the dimensions of the master to use as reference and measures the
dimensionaldi󰀨erencewiththeworkpiece.
4
2
1 3
0
F2
1 Conrmthattheproductisinincrementalmeasurement(INCdisplayis
turned on).
Tips
If set to absolute measurement, switch the measurement system to incremental
measurement. For details, see
"3.5 Switching Measurement Systems" on page 18.
2 Set the master to use for reference.
3 Press the [F2] key.
» The displayed value is set to zero.
4 Replace the master with the workpiece and perform incremental
measurement.
