Mitutoyo ID-C Series User Manual

42
5 Setting Parameters
No. 99MAH056A
(Short press) / (Long press)
5.4
Selecting Counting Direction
The counting direction can be selected with regard to the plunger movement
direction.
2 31
F2 F2
F1/F3
Positive counting
Negative counting
Go to the
next item
1 Press the [F2] key.
» The counting direction can be selected.
2 Press the [F1] key or [F3] key to select the counting direction.
 [▼]OFF:Countsup(positivecounting)whentheplungerisraised.
 [▼]Blinking:Countsdown(negativecounting)whentheplungerisraised.
» Each time the key is pressed, it will switch the counting direction.
3 Press the [F2] key.
» Settingsareconrmed;shiftstothenextparameteritem.
(Go to "5.5 Selecting Resolution" on page 44.)
