Mitutoyo ID-C Series User Manual

78
7 Low Measuring Force Types
No. 99MAH056A
y ID-C1012CNX, ID-C1012CNXB, ID-C1012CMNX, ID-C1012CMNXB,
ID-C1012CENX, ID-C1012CENXB
Coil spring attached
No weight Weight attached
0.1 N
OK
≤0.4N
OK
≤0.5N
OK
≤0.3N
OK
≤0.3N
OK
≤0.2N
No coil spring
: Factory default conditions : Not a guaranteed operation posture
Tips
• If an optional contact point or extension rod for the dial indicator is mounted,
measuring force changes and operation posture will be restricted in some cases.
• Store the removed coil spring, cap, and weight to prevent loss.
