Description of the unit
28 Operating instructions
Symbol Display element Function
Tab A
blue
and a
green
tab are located on the left side
of the touchscreen. The tabs are available only in
the cooking step display.
Tapping the tabs offers quick access to equipment
functions and cooking program functions.
Display Displays are information-containing areas in
windows.
Displays show entries and current information
some of which may be operated by tapping.
Symbol Symbols are graphical elements in windows and in
the toolbar.
Symbols indicate current states and possible
functions some of which may be operated by
tapping.
Roller Rollers are areas where settings can be made by
means of wiping gestures.
Lock This symbol indicates that screen lock has been
activated. Only the lock symbol is active.
If the operator taps on the lock symbol, a numeric
keypad appears. The screen is unlocked by
entering a specific combination of numbers.
10013865-0ABBE-B
