MKN FKECOD615T - Loading Capacity; Plate Capacity During Regeneration; Standard Setting Values; Core Temperature Standard Setting

Description of the unit
29Operating instructions
3.5 Loading capacity
3.5.1 Plate capacity during regeneration
Cooking time and cooking temperature depend on the number of
plates.
Version Plate diameter
26 cm 28 cm 32 cm
6.15 30 24 22
6.21 30 24 22
10.15 50 40 40
10.21 50 40 40
20.15 100 80 80
20.21 120 120 80
on 1/1 GN grate Tray rack or tray trolley
3.5.2 Loading capacity
Tray rack trolley and tray trolley
Version Per shelf maximum (kg) Per unit maximum (kg)
6.15 15 50
6.21 15 50
10.15 15 80
10.21 15 80
20.15 15 150
20.21 15 150
3.6 Standard setting values
3.6.1 Core temperature standard setting
The adjustment range for the core temperature depends on the
cooking mode.
Cooking mode Standard value
(°C)
Adjustment
range (°C)
Alteration
increments (°C)
Steaming 70 0 - 99 1
Combisteaming 70 0 - 99 1
Hot air 70 0 - 99 1
Regeneration 50 0 - 99 1
10013865-0ABBE-B
