9BAppendix A: Product Specifications 80BTroubleshooting
89
Time Response
Pressure Measurement
Response
Polled Communication
Response
Less than 30 ms with no digital filtering.
1 ms, maximum
Media Compatibility Any gas compatible with Iconel 600 Series and 316 SS
Physical Specifications
Dimensions
Diameter
Length
3.13” outside diameter
3.875” overall not including port tube or DeviceNet
connector
Fittings
Standard
Optional
½ inch (12.7 mm) tubulation
8-VCR
®
(female), Mini-CF (rotatable),
NM-16-KF, Swagelok 8-VCO
®
(female)
Internal Volume < 7 CC
I/O Connectors
Analog
Digital
9-pin female Type DE-9S Interface
5-pin male DeviceNet Micro-Style
Weight 1.5 lbs (0.68 kg)
Wetted Materials Inconel 600 Series (316 SS fittings)
Due to continuing research and development activities, these product specifications are subject to change without notice.
