Symbols Found on the Unit
The following table describes symbols that may be found on the unit.
Table 1: Definition of Symbols Found on the Unit
|
On (Supply)
IEC 417, No.5007
Off (Supply)
IEC 417, No.5008
Earth (ground)
IEC 417, No.5017
Protective earth
(ground)
IEC 417, No.5019
Frame or chassis
IEC 417, No.5020
Equipotentiality
IEC 417, No.5021
Direct current
IEC 417, No.5031
A
lternating current
IEC 417, No.5032
Both direct and
alternating current
IEC 417, No.5033-a
Class ll equipment
IEC 417, No.5172-a
Three phase
alternating current
IEC 617-2 No.020206
Caution, refer to
accompanying
documents
ISO 3864, No.B.3.1
Caution, risk of
electric shock
ISO 3864, No.B.3.6
Caution, hot surface
IEC 417, No.5041
