Get Attribute Single
The Get_Attribute_Single service (ID #0E) reads the value of an object instance attribute. This
service is valid for every object in your device. Table 53 lists the parameters for this DeviceNet
common service.
Table 53: Get Attribute Single Parameters
Parameter Request Response
Service
Data Type Description
Attribute ID Mandatory Conditional Network
Specific
Attribute Identifier of the attribute
whose value is being requested.
Attribute
Value
— Mandatory Context
Specific
Value of the attribute being
requested.
Set Attribute Single
The Set_Attribute_Single service (ID #10) modifies the value of an object instance attribute. If
necessary, the attribute value also is saved to nonvolatile memory. This service is valid for every
object in your device, except the Assembly Object. Table 54 lists the parameters for this
DeviceNet common service.
Table 54: Set Attribute Single Parameters
Parameter Request Response
Service
Data Type Description
Attribute ID Mandatory Conditional Network
Specific
Attribute Identifier of the attribute
whose value is being requested.
Attribute
Value
Mandatory Conditional Context
Specific
Value of the attribute being
modified.
