MKS Baratron DMA Series User Manual

74BConnection Object 7BChapter Four: Operation
64
Table 32: Poll Response Assembly Instance 2
Data Byte 0 1 2
Description
Exception Status 16-Bit Pressure
Class Code (hex)
Object Model
0x30
Device Supervisor
0x31
S-Analog Sensor
Instance ID # (hex)
0x01 0x01
Attribute ID # (hex)
0x0C 0x06
Data Type
USINT INT
Poll Response Assembly Instance #5
Poll assembly instance 5 reports the exception status from the S-Device Supervisor Object (refer
to Exception Status, page 75) and the corrected pressure value in units from the S-Analog Sensor
Object (refer to Reporting the Pressure Value, page 31) in the format shown in Table 33. Refer to
Assem
bly Instance ID #05 in the Poll Response Assem
bly (Table 25, page 58).
Table 33: Poll Response Assembly Instance 5
Data Byte 0 1 2 3 4
Description
Exception Status Corrected Pressure
Class Code (hex)
Object Model
0x30
Device Supervisor
0x31
S-Analog Sensor
01 0x01 0x01
Attribute ID # (hex)
0x0C 0x06
Data Type
USINT REAL
Connection Object Supported Services
The Connection Object is supported by the three DeviceNet common services listed in Table 34.
Refer to Supported Service Summary, page 103, for more information.
Table 34: Connection Object Supported Services
Service ID #
(hex)
Service
Name
Parameter
Data Type(s)
Service
Type Description
05 Reset USINT Request Places the object into its
Initializing state.
0E Get_Attribute_Single USINT Request Reads the object attribute.
10 Set_Attribute_Single USINT,
Attribute Data
Type
Request Modifies the object attribute.
