MKS Baratron DMA Series User Manual

75BS-Analog Sensor Object 7BChapter Four: Operation
70
Code DEC Symbol Name Conversion Factor
1001
hex
4097 Counts Full Scale Counts 29788=100% Full Scale
1007
hex
4103 Percent % Full Scale 100.00 (Base % Full Scale)
1300
hex
4864 Psi (pound-force)/(inch)
2
0.0193368 (Base Torr)
1301
hex
4865 Torr
mmHg (0° C)
1.0 (Base Torr)
1302
hex
4866 mTorr mTorr 1000.0 (Base Torr)
1304
hex
4868
inHg (0° C) inch of mercury (0° C)
0.0393701 (Base Torr)
1305
hex
4869
cmH
2
O (4° C) centimeter of water (4° C)
1.35955 (Base Torr)
1306
hex
4870
inH
2
O (4° C) inch of water (4° C)
0.535254 (Base Torr)
1307
hex
4871 bar bar 0.00133322 (Base Torr)
1308
hex
4872 mbar millibar 1.33322 (Base Torr)
1309
hex
4873 Pa pascal N/(m)
2
133.322 (Base Torr)
130A
hex
4874 kPa kilopascal 0.133322 (Base Torr)
130B
hex
4875 atm standard atmosphere 0.00131579 (Base Torr)
130C
hex
4876 gram/cm
2
gram-force per square
centimeter
1.359510250028 (Base Torr)
Specific Services
Table 39: S-Analog Sensor Object Specific Services
Service Code
(dec) (hex)
Service
Name/
Access Rule Description of Service
53 0x32 U-Coarse
Zero
Adjustment
Sends a Target pressure value, usually zero, to the device. Corrections
to the digital zero are made to bring the pressure Value (Attribute 0x6)
to the specified Target Value. The range of this service is –4 to +20%
of Full Scale. This service is also initiated by depressing the Coarse
Zero Push Button for at least 2 seconds.
75 0x4B U-Fine Zero
Adjust
Sends a Target pressure value, usually zero, to the device. The value of
Offset-B (Attribute 0x10) is modified to bring the pressure Value
(Attribute 0x6) to the specified Target Value. The range of this service
is ±2% of Full Scale.
76 0x4C U-Gain
Adjust
Sends a Target pressure value to the device. The value of the Gain
(Attribute 0x0E) is then modified to bring the pressure Value
(Attribute 0x6) to the specified Target Value. Valid gain values range
from 0.98 to 1.02.
