80BTroubleshooting 9BAppendix A: Product Specifications
86
Electrical Specifications
DMA (Ambient) DMA (45° C) DMA (80° C)
CE Compliance
Electromagnetic
Compatibility
1
Pending Specification EN61326
EMC Directive 2004/108/EEC
+11 to +25 VDC *
200 mAmps (max)
500 [1] V
+11 to +25 VDC *
700 mAmps (max)
500 [1] V
+11 to +25 VDC *
1.0 amps
500 [1] V
Input Power Requirements
Voltage
Current at Warm Up
Isolation
* Communicate within +11 to +25 VDC range.
Operation within performance specifications from +18 to +25
VDC.
Power Consumption
≤ 7 Watts ≤ 14 Watts ≤ 22 Watts
Protection
Fuses
Tantalum Capacitors
Mis-wiring
Transients
Current limiting provided on DeviceNet power supply inputs.
Target use restricted.
Protection against on DeviceNet Connector.
Protection against per CE.
Signal Output—Analog -0.5 to +11 V (0 to 10 VDC for 0 to 100% Full Scale)
Supply Voltage
Coefficient
Span
Zero
0.02% Reading for 18 VDC to 25 VDC
0.01% Full Scale for 18 VDC to 25 VDC
1
Overall metal braided shielded cable, properly grounded at both ends, for use of J2 9-pin “D” connector.
