Table 45: Exception Detail Alarm Bytes
Byte Description
0 2 Number of Common Alarm Detail Bytes
1 XXXXXXXX Common Alarm Detail Byte 0
2 XXXXXXXX Common Alarm Detail Byte 1
3 2 Number of Device Alarm Detail Bytes
4 XXXXXXXX Device Alarm Detail Byte 0
5 XXXXXXXX Device Alarm Detail Byte 1
6 1 Number of Manufacturer Alarm Detail Bytes
7 XXXXXXXX Manufacturer Alarm Detail Byte 0
Refer also to Table 47, page 79.
Exception Detail Warning
Attribute ID #14 identifies the specific warning condition(s) detected by the DMA transducer.
This attribute is a Structure of three Structures containing a bit ma
pped representation of the
warning detail. This structure contains a total of 9 bytes. The first group contains 3 bytes
representing Common Exception Detail Warning Bytes. The second group contains 4 bytes
representing Device Exception Detail Warning Bytes. The third group contains 2 bytes
representing Manufacturer Exception Detail Warning Bytes.
The response is a byte with each bit representing a specific exception (alarm) condition, as listed
in Table 46. The bit that is set indicates that the alarm
assigned to that bit is active. The response
returns a binary (hex) value with the least signi
ficant bit (bit 0) as the last digit. The response
values are additive; therefore, one hex value reports all alarm conditions.
Table 46: Exception Detail Warning Bytes
Byte Description
0
2 Number of Common Warning Detail Bytes
1
XXXXXXXX Common Warning Detail Byte 0
2
XXXXXXXX Common Warning Detail Byte 1
3
3 Number of Device Warning Detail Bytes
4
XXXXXXXX Device Warning Detail Byte 0
5
XXXXXXXX Device Warning Detail Byte 1
6
XXXXXXXX Device Warning Detail Byte 2
7
1 Number of Device Warning Detail Bytes
8
XXXXXXXX Manufacturer Warning Detail Byte 0
Refer also to Table 47, page 79.
