MKS Baratron DMA Series User Manual

11BAppendix C: Command Summary 83BSupported Service Summary
107
Restore Default
The Restore_Default service (ID #15) restores attributes in the specified object to their factory
default values. This service is valid for the Analog Input, Output Pressure, Device Configuration,
Trip Point, and SAC Objects. Table 55 lists the parameters for this DeviceNet common service.
Table 55: Restore Default Service Parameters
Parameter Request Response
Service
Data Type Description
Restore
Conditions
Mandatory Conditional USINT 0 = Restore specific attribute of
the object.
1 = Restore all attributes of the
object.
2 = Restore all S, A, and C
objects*.
Attribute
Value
Conditional Conditional Network
Specific
Attribute ID of the attribute
whose value is being restored.
* The S, A, and C Objects include the Analog Input, Output Pressure, Trip Point, and Device
Configuration Objects.
Allocate Master/Slave
The Allocate_Master_Slave service (ID #4B)—valid only for the DeviceNet Object—supports
and allocates the explicit and I/O poll messaging connections of the Predefined Master/Slave
Connection Set [1]. Table 56 lists the parameters for this DeviceNet common service. For
complete information on this service, refer to the ODVA “DeviceNet Specification,” Volume I
[1].
Table 56: Allocate Master/Slave Parameters
Parameter Data Type Description
Allocation
Choice
BYTE Indicates which connections from the Predefined Master/Slave
Connection Set are to be allocated/configured for use by the
Master.
Allocator’s Node
Address
USINT Contains the Node Address associated with the module
requesting the allocation.
