Table 19: Object Classes in the DMA Transducer
Object Class
Class
ID Effect on Behavior
Refer to
Page
Identity 01
hex
Supports the Reset services. Upon receipt
of a Reset service request of any type, the
Identity Object sends a Reset service
request to the S-Device Supervisor.
53
DeviceNet 03
hex
Configures port attributes (node addresses,
data rate, and BOI)
55
Assembly 04
hex
Defines input/output and configuration
data format.
58
Connection Class 05
hex
Contains the number of logical ports into
or out of the device.
60
S-Analog Sensor 31
hex
The instance of this object provides a
calibrated pressure value from a pressure
transducer. The instance is using S-Analog
Sensor subclass number 3, Capacitance
Manometer.
65
Device Configuration 6D
hex
General Device Configuration settings not
available in other objects.
71
S-Device Supervisor 30
hex
Supports the Stop, Start, Reset, Abort,
Recover, and Perform Diagnostic services
for ALL Application Objects in the device
and consolidates the Exception Conditions
and Application Objects’ Status.
This object behaves differently from the
Identity Object in that the S-Device
Supervisor object provides a single point
of access to the Application Objects only.
It does not affect the DeviceNet objects
(Identity, DeviceNet, Connection, etc.).
72
